Voltage Transformer JDZ1-1 JDZ2-1 from JUCRO Electric

1.Rated voltage :3kv ,6kv ,10kv ,11kv
2.Indoor, cast resin epoxy type

Voltage Transformer JDZ1-1 JDZ2-1 from JUCRO Electric

Quantity

Product Detail

Voltage Transformer JDZ1-1 JDZ2-1 from JUCRO EleCTric


DescriPTion



The current transformer is used for measuring electric energy and voltage, relay protection in the electric systems up to rated frequency 50Hz or 60Hz and rated voltage 1kV.

 Type description


Construction



  The product is of insulated structure cast with epoxy and piled-shape core wound by primary and secondary windlings. The lead of secondary is out through called a.x. The lead of the primary is out through to high-Tention terminals called A.X.



 Technical data


Voltage transformers are in accordance with the

Chinese standards GB1207-75

Rated voltage ratio

380,660/100

660,1140/100

750,1500/100

Frequency(Hz)

50

50

50

Rated output(VA)

For accuracy class

5

5

5

Insulation level(kV)

0.66/3.6

   1.14/3.6

   1.5/3.6


When ordering, please specify the following

Insulation level

ratio primary and secondary voltage

Number of cores, output and accuracy class

Test specification




No comment

Product Detail

Voltage Transformer JDZ1-1 JDZ2-1 from JUCRO EleCTric


DescriPTion



The current transformer is used for measuring electric energy and voltage, relay protection in the electric systems up to rated frequency 50Hz or 60Hz and rated voltage 1kV.

 Type description


Construction



  The product is of insulated structure cast with epoxy and piled-shape core wound by primary and secondary windlings. The lead of secondary is out through called a.x. The lead of the primary is out through to high-Tention terminals called A.X.



 Technical data


Voltage transformers are in accordance with the

Chinese standards GB1207-75

Rated voltage ratio

380,660/100

660,1140/100

750,1500/100

Frequency(Hz)

50

50

50

Rated output(VA)

For accuracy class

5

5

5

Insulation level(kV)

0.66/3.6

   1.14/3.6

   1.5/3.6


When ordering, please specify the following

Insulation level

ratio primary and secondary voltage

Number of cores, output and accuracy class

Test specification




Voltage Transformer JDZ1-1 JDZ2-1 from JUCRO Electric
1.Rated voltage :3kv ,6kv ,10kv ,11kv
2.Indoor, cast resin epoxy type
