特征说明 CHARACTERISTICS | |
材 质 Material | 锌合金铰链,碳钢销子 Zinc alloy Hinge, carbon steel pin |
Surface treatment | 镀亮光铬,销子镀蓝白锌 Bright chrome plated, blue white zinc plated for pin |
结构说明 Structure descriPTion | 可开启角度180° Opening angle 180° |
性能参数 PERFORMANCE PARAMETERS | |
径向载荷 The radial load | 1500N |
轴向载荷 The axial load | 1800N |
固定螺母的推荐拧紧力矩 Recommended nut tightening torque | 10N.m |
外型及安装尺寸 APPEARANCE AND INSTALLING DIMENSION |
Unit:mm |
