Vacuum ContaCTor HVJ5 1.14KV 63A 80A from JUCRO Electric
1. General
HVJ5-1.14/63(80)B AC Vacuum Contactor is designed for long-distance making and breaking of circuit, frequent starting and controlling of AC motors in the power systems, with AC 50Hz-60Hz, rated voltage of 1,140V and rated current to 80A. It also can be equipped with thermal relay and all kinds of protection apparatus like electromagnetic starter, especially applied to explosion-proof starter and so on.
2. Main technical parameter
Product model | Rated voltage (V) | Rated current（Main circuit）A | Main contacts parameters | Power frequency voltage | ||||||
Main circuit | Control circuit | Opening distance（mm） | Over travel | Final pressure | ||||||
Main circuit | Auxiliary circuit | Control circuit | ||||||||
HVJ5-1.14/63B | 1140 | 36.110.220.380 | 63 | 1.8±0.2 | 1±0.2 | 30±3 | 4200 | 2500 | 2000 | |
HVJ5-1.14/80B | 1140 | 36.110.220.380 | 80 | 1.8±0.2 | 1±0.2 | 30±3 | 4200 | 2500 | 2000 | |
Product model | Making capacity | Breaking capacity | Limit breaking current(A) | Electricity life times | Mechanical life times | Overload capacity | |
AC3 | AC4 | ||||||
HVJ5-1.14/63B | 10In,100times | 8In,25 times | 2000,3 times | 60*104 | 6*104 | 300*104 | 8In 10S |
HVJ5-1.14/80B | 10In,100times | 8In,25 times | 2000,3 times | 60*104 | 6*104 | 300*104 | 8In 10S |
Remark: “In” is Rated current of main circuit.
